Patch-cord optical FTTH 1SM

Number of fiber strands;1; Cable dimensions, mm;3*2 Fiber type (conforms to ITU-T);9/125 (G/657.A2) Cable jacket composition; LSZH Jacket color; White (UV resistant) Power element; two FRP bars Power element diameter, mm; 0,5 Minimum bend radius, mm; 30 (loaded) 15 (when installed) Typical attenuation, dB/km; 0.4 at 1310 nm 0.3 at 1550 nm Max. tensile load;0.25 kN Max. compression load;N/100 mm 1000 Connector type;SC/ACP SC/UPC Cable lengths are made according to customer's request;
